REACTOR CUSTOM AIR CORE LINE COILS UNUSED SPARES

No longer available
REACTOR CUSTOM AIR CORE LINE COILS UNUSED SPARES
Description
Three Units Available
AIR CORE LINE REACTOR 1.000
Three 1-Phase Units required for 3-Phase
operation:
CUSTOM AIR CORE LINE REACTOR
4160V 3PH 2000A
3 each stacked
Type: Air Core Current Limiting Reactor
Phase: 1
Rated Frequency: 60Hz
Winding Material: Copper
Rated Current: 2000A
Rated Voltage: 4160V
BIL: 65kV
Rated Inductance: 0.04 Ohm
Temp Rise: 80 deg C
Insulation Class: 220 deg C
Cooling: ANN
Impregnation: VPI polyester resin
Indoor Application
Estimated dimensions: 45" OD X 52" High
Estimated weight: 1000 Lbs
Specifications
Manufacturer | HAMMOND POWER SOLUTIONS |
Model | REACTOR AIR CORE |
Condition | Used |
Stock Number | 903594.007 |
Type | Air Core Current Limiting Reactor |
Phase | 1 |
Rated frequency | 60Hz |
Winding material | Copper |
Rated current | 2000A |
Rated voltage | 4160V |
Bil | 65kV |
Rated inductance | 0.04 Ohm |
Temp rise | 80 deg C |
Insulation class | 220 deg C |
Cooling | ANN |
Impregnation | VPI polyester resin |
Estimated dimensions | 45" OD X 52" High |
Estimated weight | 1000 Lbs |
