73" WIDE BW PAPERSYSTEMS / MARQUIP SHEETPRO DUAL ROTARY SHEETER WITH D2 SPLICER

73" BW Papersystems / Marquip SheetPro Dual Rotary Sheeter

Year Manufactured: 2006

Material processed: SBS, SUS, clay-coated newsback, chip & polycoated paperboard. Foil laminates & preprint surfaces

Running web width range: 17" - 73" (webs can run side by side)

Maximum two ply

Dual position unwind stand, 72" diameter

D2 Splicer installed 2021. Bobst decurler, rotary dancer & 3 bar progressive decurler

Core sizes: 3" & 12"

Maximum roll weight: 8,800 lbs for 72" diameter rolls

Pneumatic brakes & 12" chucks

Dual web aligner system

Marquip cut off knife: .20 to 1mm (.008 to .040")

Marquip cut off knife: 200 to 1000 gsm (40-220lb/1000ft squared)

Heavy duty pull roll

Max mechanical speed: 1100 fpm (material dependent)

Sheet length range: 18" - 65" long

Sheet width range: 11" (minimum slit width) - 73" wide

Slitting: Tidland Class 3 pneumatic shear slitting knife holders

High speed knife outfeed tape belt section with reject gate & vacuum modulator

Static bar

Dual vacuum modulated overlap

Accumulation conveyor

Tamper & backstop

Model 1 Stacker section, 72" max pile height by 65" long max pile length, 6000 lb max weight

Danfoss Drives and HMI Update

S/N 94924-1100

Footprint appx: 84' long by 33' wide by 15'4" tall

Complete documentation available on site

Plant Closing June 2025
