28" ASSOCIATED MACHINE DESIGN REM DUPLEX SLITTER REWINDER MODEL 3250.74

28" ASSOCIATED MACHINE DESIGN REM DUPLEX SLITTER REWINDER MODEL 3250.74

Contact us for price

orCall +1 215-664-6016

Description

903514 One (1) Used 28" REM Duplex Slitter Rewinder *Razor comb seems to be the limiting factor on material width. Should be able get to 30" wide with larger trim or more wide razor comb. Model #: 3250.74 Serial #: 3317E Working width: 28" Unwind diameter: 26" Max parent roll weights: 500 lbs Razor in comb slitting ; 1/16" increments 1" Minimum slit width Cantilevered rewind shafts w/ support arms Rewind diameter: 18" max on 3" cores Rewind shafts included: 1" and 3" differential shafts; spacer style. Can be upgraded. Speed: 500 ft/min Fife edge guide. Automatic unwind tension control with the diameter being sensed by an ultrasonic sensor and tension being controlled by PLC. Automatic rewind tension control and taper control by means of diameter calculation through the PLC. The operator sets starting pressure and amount of taper for each rewind station. 460/3/60 Plant Voltage 80 PSI, 5 CFM Rebuilt by REM in 2017

Specifications

ManufacturerASSOCIATED MACHINE DESIGN REM
Model3250.74
ConditionUsed
Serial Number3317E
Stock Number903514.002
Width28
Rewind diameter18" max on 3" cores
Model #3250.74
Serial #3317E
Working width28"
Unwind diameter26"
Max parent roll weights500 lbs
Rewind shafts included1" and 3" differential shafts; spacer style. Can be upgraded.
Speed500 ft/min
