52" W&H NOVOLEX 10 COLOR CI PRITING PRESS MFG. 2003

107923 One (1) Used 52" W&H Novoflex 10 Color CI Printing Press Mfg. 2003 A very nice clean press in daily production, can be seen running. Updated Central Computer controls with new touch screens and operator pendants. Ethernet diagnostic access. Everything in 100% working condition. Take possession when replacement is in and running estimated at 1 April, 2020 Repeat Range: 14.5:" - 30" Number of Color 10 Ink Metering System Chamber Doctor Blades Maximum Web Width 52" Maximum Print Width 51" Unwind Type Auto splice turret, w/roll lift table Maximum Unwind Diameter 31.5" Max Diameter Rewind Type Auto splice turret Maximum Rewind Diameter 31.5" Max Dimeter Core Shaft sizes 3" and 6" Dryer Between color and tunnel Heat Source Natural Gas, with LEL monito Maximum Design Speed 1300 FPM Age 2003 Power 460/480 V, 60Hz, 3 Phase Auxiliary Equipment Included with Machine: Edge Guides In feed & out feed Anilox Roll sleeves Approximately 12 Plate Cylinder Sleeves Approximately 50 Hastiloy coated CI drum Yes Two scissor lift platforms to access color decks for sleeve changes, with sleeve extraction system for both plate cylinder and anilox sleeves Motorized web thread up Yes Web inspection system AVT, defect detection Auto wash up W & H updated Turbo Clean 600A Ink Pumps Yanmada Viscosity controls Norcross Electronic Control room Yes Deck Positioning Yes Corona Treater Enercon 7.5 KW Spare parts Yes, to be determined In line slitting Razor
