400 MW WESTINGHOUSE/SIEMENS GAS POWERED TURBINE GENERATION SYSTEM

400 MW WESTINGHOUSE/SIEMENS GAS POWERED TURBINE GENERATION SYSTEM

Contact us for price

orCall +1 215-664-6016

Description

107469 One (1) Used 100 MW Westinghouse/Siemens Gas Turbine Generator 4 x 100 MW Units - can be sold individually Model: W501D5 HZ: 60hz Fuel Type: LNG New in 1995 Gas Turbines Type : Axial Flow Power Output : 100, 000 kW (100MW) Stages : 4 stage Inlet Temp. : 1093 C Exhaust Temp. : 530 C Exhaust Flow : 1313272 kg/h TAC Temp. : 15 C Speed Governor : DEHC Starter System Type : Electric Motor Capacity : 1530 kW Quantity : 1 ea Combustor Type : Can-Annular Quantity : 14 ea Compressor Type : Axial Flow Air Mass Flow : 358 Nm/min Inlet Temp. : 15 C Pressure Ratio : 14:01 Outlet Pressure : 14.462 kg/cm2 Stages : 19 stage Outlet Temp. : 389 C 2.Generators Manufacturer : WESTINGHOUSE(SIEMENS) Type : OAC(Open-Air-Cooled) Rated Power : 129(143) MW(MVA) Power Factor/ short-circuit ratio : 90%/0.695 Frequency : 60Hz/2pole Speed : 3600 RPM Rated Voltage/Current : 13.8 kV/5731 A Insulation Class : F Exciter Speed : 3600 RPM Exciter Type : PMG Rated Voltage/Current 325 V/1006 A Protection Devices : 87G, 59GN, 40, 32, 46, 51V, 60, 25 Neutral Grounding : NGR Bus Bar : IPB(3phases) Rotation Direction : CW(Viewed Form Exciter end) 3.Operation hours Gas Turbine #1. 37, 566hours(1996.1~2013.6) Gas Turbine #3. 39, 800hours(1996.1~2013.6) Gas Turbine #4. 41, 541hours(1996.7~2013.6) Gas Turbine #5 41, 819hours(1996.7~2013.6) 4.Operation hours from overhaul to stop Gas turbine #1: 18, 117 hours Gas turbine #3: 17, 098 hours Gas turbine #4: 15, 686 hours Gas turbine #5: 17, 978 hours 5.Generator serial number Generator#1. 93P0621 Generator#3. 93P0635 Generator#4. 93P0684 Generator#5. 93P0695 6.Scope of supply Turbine Generator Control panel(Electric package) Switchgear box Mechanical room equipment Currently installed with target dismantling schedule during early 2017

Specifications

ManufacturerWESTINGHOUSE(SIEMENS)
ModelW501D5
ConditionUsed
Stock Number107469
Hz60hz
Fuel typeLNG
TypeOAC(Open-Air-Cooled)
Power output100, 000 kW (100MW)
Stages19 stage
Inlet temp.15 C
Exhaust temp.530 C
Exhaust flow1313272 kg/h
Tac temp.15 C
Speed governorDEHC
Capacity1530 kW
Quantity14 ea
Air mass flow358 Nm/min
Outlet pressure14.462 kg/cm2
Outlet temp.389 C
Rated power129(143) MW(MVA)
Power factor/ short-circuit ratio90%/0.695
Frequency60Hz/2pole
Speed3600 RPM
Rated voltage/current13.8 kV/5731 A
Insulation classF
Exciter typePMG
Protection devices87G, 59GN, 40, 32, 46, 51V, 60, 25
Neutral groundingNGR
Bus barIPB(3phases)
Rotation directionCW(Viewed Form Exciter end)
Gas turbine #118, 117 hours
Gas turbine #317, 098 hours
Gas turbine #415, 686 hours
Gas turbine #517, 978 hours
